LNJS-5018B Scissor Lift for wheel alignment - Yantai Lion Automobile Equipment Co.Ltd. Official Website

1.Recess mounted installation occupies less space. A lift capacity of 5T can meet requirements of various vehicles.
2.6mm whole board bending benches adapt to various vehicles and there are also platforms of 4500mm as an alternative.
3.The lift is equipped with two second lifting devices’ moving flexibly and easily operated. With extended side slide’ it adapts to vehicles of various wheelbases. The lift can be used for SUV and business vehicles.
4.The use of mechanical safe lock’ explosion -proof valves and self-lock of hydraulic systems ensure a safe work.
5.Integrated PLC computer controller features self-testing function’ offering guidance in eliminating faults and ensure safe voltage.
6.Tandem synchronous cylinder ensures sychronous bench lifting’ which not only prevent rollovers of vehicles’ but also provide a precisely level surface for wheel alignment. It adapts to different types of wheel alignment machines.
7.Imported oil seals from Italy prolongs the life of the cylinder. Imported manual oil-input valves from Italy avoid oil leakage inside’ and no need to fill oil frequently for rebalance.
8.Maximum limit mitigates abrasion of hydro-cylinder and overload of hydraulic systems’ which prolongs usage life of the machine.
9.Sound and light alarms during the descending of the machine ensures safety.
10.The surface adopts the static powder coating’ so it is of anti-erosion’ good adhesion and high hardness.
11.Double deck steel oil pipe achieves good explosion-proof performance.

12.With high quality international-standard steel as raw materials’ the equipment has bigger self-weight compared to homogeneous ones. Holes of front arms are made with CNC sawing machine to ensure same heights.

13.120% dynamic loading test and 150% static loading test comply with CE standard
