l Product Functions & Features:

1、 Measurable Parameters: Camber’Caster’SAI’Toe’Setback’ Thrust Angle’Axis Deviation’Lateral Deviation’Wheelbase’ Tread’ Tire Diameter’Toe-out-on-Turn’Maximum Turn Angle

2、 Extensive Dadabase: Cover more than 20’000 vehicle model alignment specification and adjust help. New data can be added by customer.

3、 Maintenance free’no electric parts in targets’no need routine calibration’low service costs.

4、 Simple and user friendly operation’quick and intuitive to master’increase work efficency.

5、 Advanced intelligent error correcting system’automatically compensate deformed wheel’target installtion offset and unlevel of lift platforms as well as electron drift of electric parts.

6、 Advanced lights filtering system to prevent interfere from ambient lights and direct sunlight’ensure a precise measurement.

7、 Advanced Free-push technology’no pause during vehicle pushing and steering wheel turning’reduce labor intensity and increase operating efficiency.

8、 Advanced dynamic measuring technology’finish basic alignment measuring in 2 minutes.

9、 Patented intelligent operation indicating system’instruct the operator in distant to carry out measuring job’increase working efficiency.

10、 Has quick measurement function’ measurement results turn out by a simple vehicle push.

11、 Patented 3 intelligent control systems’significently increase working life of core electric parts and reduce energy consumption.

12、 Dynamic animated display’easy understand’lower the technology threshold for mechanic freshman.

13、 The equipment needs calibration only once in factory’ no need recalibration after installation.

14、 Has intelligent customer reminder system’can be a good help to increase customer satisfaction.

15、 Intelligent diagnose system’can find out abnormal process or failure of hardwares connection.

16、 With 3 intelligent control systems’ can significently prolong working life of core devices.

17、 Intelligent identify vehicle push direction and steering wheel turn direction’save walking trips to the console to click mouse.

18、 Targets intelligent monitoring and warning system.

19、 Micro-distance vehicle push (optional)

l Ambient Requirements: Temperature:-20℃～50℃ Humidity: ≤90%n Power Supply: 220V/50H

Must use independant power source not share with other big power equipment
